Sound insulation level: 10-25dB.
Applicable fields: highways, railways, elevated bridges, residential areas, factories, etc.
Common specifications:
Styles: louver holes, micro holes (round holes), pressed tile type, upright type, curved type.
Sound barrier height: 2m-7m.
Column spacing: 2000mm, 2500mm, 3000mm.
H-shaped steel columns: 100 * 100, 125 * 125, 150 * 150, 175 * 175.
The thickness of the metal screen body is 80mm, 100mm, and 120mm.
Metal screen material: color steel plate, galvanized plate, aluminum plate
Transparent screen material: PC board, acrylic board, laminated tempered glass
Other materials: FRP, foam aluminum.
Internal filling materials of metal sound barrier: foam board, sound absorbent cotton, foam aluminum
Surface treatment: High voltage electrostatic spraying, Buddha carbon spraying
Colors: green, gray, white, blue, can be selected according to the national standard color card.
Our company can customize production according to customer requirements, including height, spacing, material, thickness, and can be combined and matched (combination materials, combination specifications, combination styles). We can also measure according to customer needs or actual on-site conditions
